Belimo NM24P servo drive
RobustLine damper actuator for controlling dampers in HVAC, similar industrial applications and technical building equipment
Description
- HVAC damper up to approx. 2 m²
- Motor torque 10 Nm
- Rated AC/DC voltage 24 V
- Open-close, 3-point control
- Optimum protection against corrosion and chemical influences, UV radiation, humidity and condensation
Data sheet
NM24P
- Power supply
- 24V AC/DC
- Actuator type:
- Damper rotatable
- Caliper range
- Ø 10...20 mm
- Electrical coverage:
- IP66/67 / NEMA 4X for outdoor applications
- Torque:
- 10 Nm
- Flap size up to approx
- 2 m²
- Emergency functions:
- NO
- Type according to conversion speed:
- Robustline for extreme conditions
- 90° motor adjustment time
- 150 s
- Control:
- O/C, 3 point
- SPDT Auxiliary Switch:
- NO
- Direction of rotation:
- Switchable mechanically
- Connection:
- Cable
Optional accessories
