Lift valve VXP45.20-4
Lift valve, 3-way, male thread
Application:
- In ventilation and air-conditioning systems for water-side control in closed circuits, e.g. In induction and fan coil units, small heaters and chillers for use in:
- 2-pipe systems with one exchanger for heating and cooling
- 4-pipe systems with two separate exchangers for heating and cooling
- In heating equipment for closed-loop control of heating zones, e.g.
- stand-alone heating equipment
- apartments
- individual rooms
- Bronze valve body CC491K (Rg5)
- DN 10...DN 40
- kvs 0,25...25m3/h
- Threaded connection G...B according to ISO 228/1 with flat seal for
- ALG... threaded connection set (supplied by Siemens)
- SERTO clamp fitting, type SO 21...
- Knob for manual operation
- For use with electric actuators SSB... or SSC...
- Kvs valve:
- 4.0 m3 /h
- DN:
- 20
- G:
- 1''
- Tap/valve connection:
- External thread
- P.N.:
- 16
- Valve design:
- Stroke, 3-way
- Stroke:
- 5.5 mm
- Use:
- Cold and hot water
- Liquid temperature:
- 1...110°C
